Description
Hull: Steel. Classification: Bureau Veritas. Total Fish Hold capacity: 200 tons. Average Fuel Consumption: 2,400 liters/day. Main Engine: ABC model 6DZC Serial Nº:14069. Accommodation: 22 Crew Members. Last Drydock: August 2024.
Specifications
| Condition: | Last Drydock: August 2024 |
| Vessel type: | Fishing Vessel / Surface Freezer Longliner |
| Constructed: | 2017 |
| Class Society: | Bureau Veritas |
| Guests: | 22 |
| No. of engines: | 1 |
| Engine model: | Main Engine: ABC model 6DZC |
| Engine power: | 1240 |
| Nominal length: | 40.80m |
| Length over all: | 40.80m |
| Beam: | 8.60m |
| Maximum draft: | 3.65m |
| Fuel capacity: | 13512 Cubic Metres |
| Water capacity: | 608 Cubic Metres |
Accommodation
22 Crew Members
Construction
Type of Vessel: Surface Freezer Longliner
Hull: Steel
Year of Construction: 2017
Classification: Bureau Veritas
LOA: 40.80m
LBP: 32.85m
Beam: 8.60m
Depth: 6.00m
Draft: 3.65m
GT: 498 t
NT: 149 t
Total Fish Hold capacity: 200 tons
(140 t in the hold + 50 t in the tween deck + 10 t in the freezing tunnels)
Fuel capacity (approx.): 135.12 m³
Average Fuel Consumption: 2,400 liters/day
Oil capacity: 8.93 m³
Fresh Water capacity: 6,08 m³
Refrigerant R-404-A. Cooling system: DIRECT EXPANSION.
Freezing Capacity: 7-8 tons/day
2x Freezing Tunnels
2x Bitzer OSN-7471K
1x Bitzer OSN-7441K
1x Bitzer 4FES-3Y
Equipment
2x Hydraulic Cranes Lifting Capacity: 1,20 Tm y 0,7650 Tm
1x Servo Motor Lifting Capacity: 5 Tm
1x Windlass
3x Bilge Pumps AZCUE, Power: 5,50 kW; Flow rate: 30 m³/h; Pressure:2,80 kg/cm2
1x Fuel Transfer Pump Power: 7,50 kW; Flow rate: 3 m³/h; Pressure: 3 kg/cm2
2x Fresh Water Pumps Power: 1,50 kW; Flow rate: 40 m³/h; Pressure: 2,50 kg/cm2
2x Sea Water Pumps Power: 1,50 kW; Flow rate: 40 m³/h; Pressure: 2,50 kg/cm2
2x Air Compressors Power 7,50 kW, Pressure: 30 kg/cm 2
2x Starting Air Bottles Pressure: 30 bar; Capacity: 125 l
1x Oil Separator DELTA, Capacity: 0,50 m³/h
Engine(s)
Main Engine: ABC model 6DZC Serial Nº:14069
Power: 1.240 HP / 925 KW
Reduction Ger: Reinjest WAF1143, Ratio: 3,037/1
Propeller Shaft: 197 mm
Generator: Stamford, Power: 248 kW
3x Cummins QSM11-DM-HCM434F1, Power: 265 KW
Electronics
Modern & Fully Equipped:
SOLAS Echo Sounder FURUNO FE-800
Non- SOLAS Echo Sounder FURUNO FCV-1150
NAVTEX FURUNO NX-700B
A.I.S. FURUNO FA-170
SOLAS Radar FURUNO FAR-2127
Non-SOLAS Radar FURUNO FAR-2127BB
SOLAS GPS FURUNO GP-170
3 x Non-SOLAS GPS 2 x FURUNO SC-50 and 1 x FURUNO GP-39
Certification
Last Drydock: August 2024
