Description

Available in aluminium or steel construction, build time 8 months from order.

This design features a large 25.0 ton SWL fixed boom crane with hydraulic extension and winch and 6 m aluminium rescue boat.

Build will be done in our own shipyard.

Specifications

Accommodation

Air Conditioning - Seawater cooled system providing cooling and redundancy throughout the vessel 45 C to 23 C

Cabins - 1 x 1 man with ensuite, 1 x 2 man in top deck. 2 x 4 man in lower deck all with lockable drawers, reading lights, privacy curtains, vertical lockers, power outlets, ladders
to upper bunks


Wheel House - High back seating for 16 persons, 3 helm seats

Top deck accommodation area - 1 x mess area with freshwater fountain, 1 x coffee machine, 1 x refrigerator, TV video with LCD screen

Galley - Upper deck fully equipped and servery for passengers with refrigeration, microwave, coffee machine, food heater and cooker

Bathrooms and Showers - 1 full bathroom with showers on Upper deck
4 each WC’s on second deck and a shower and WC for crew in lower deck

Passenger decks - Second deck 183 high back seat and 32 exterior seats Top deck 75 high back in bridge area and 14 exterior seating

Washing Machine and Dryer - 1 of each in laundry room below main deck
Electric 1 x 4 induction elements with a deep fryer
Stove and Oven / fryer -

Microwave & Convection Oven - Yes

Freezer - 1,500 litres total capacity

Cool Room - 1,000 litres fridges

Dishwasher - Yes

Ice Maker - Yes

Fresh Water - Fountain 20 litres

Coffee Maker - Nespresso

Construction

Vessel Type - Shallow draft semi displacement cargo passenger Vessel

Port of Registry - To be constructed to purchasers flag state rules

Construction - Standard construction steel hull, aluminium superstructure, full aluminium construction available @ USD $300,000 extra

Builder - Marine Frontiers Pvt Ltd on behalf of Shipco 360 Ltd

Design - Australian Marine Technology

Classification - LR 1 + Hull o Mach Cargo passenger vessel

Length Overall - 42.00 Metres

Length Waterline - 37.60 Metres

GRT/NRT - 325 / 280 Ton

Beam - 12.0 Metres

Draft - 2.3 Metres max

Passengers - 304

Crew - 6

Medical Facilities - Paramedic Standard

Equipment

Tender Vessel - 1 x 6.0 metre with inboard diesel sterndrive

Compressor - General unit 12 cfm for servicing equipment

Desalination Plant - 1 units producing 3,000 litres in 24 hours

Tools - Frontline tools, equipment and testing tools for preventative maintenance and on-board breakdowns

Spares - On-board spares for preventative maintenance and emergency backup

Fendering - Half round aluminium tube

Gangway - Portable aluminium gangway

Lines - Berthing, Towing Bridle, Heaving Line

Handling - Boat Hooks, Grapple with Lanyard

Deck Equipment - Recessed tie downs SWL 500 kgs

Mooring - Double Bit Bollards – 6 sets

Plating - 10.0 mm deck

Access to Water - Transom and side rescue zones

Anchor - 1 x 200 kgs

Anchor Winches - 1 x Electric 8 ton

Anchor Chain - 1 x 210 metre

Pillar Deck Crane - 25.0 ton SWL fixed boom crane with hydraulic extension and winch

Bilge System - Mechanical pump with electric back-up connected to manifold system.
Electric automatic pump in all spaces
Central bilge alarm panel to helm station
Manual back-up pump and bucket to meet survey

Navigation Equipment

Radar - Furuno 2 x FAR 2117

Sounder - Furuno

Plotter - Furuno

GPS - Furuno

DGPS - Furuno

GPS Plotter - Furuno

Auto Pilot - Simrad AP 70

HF / SSB Radio - Icom IC M801E c/w AT 30 auto turner

VHF Radio - Icom IC 411

Hand Held Radio - Inmarsat ASAT

Compass - Furuno SC50

AIS - Simrad MX 535 A

Search Light - Sanshin HR-1012

Intercom - GME to machinery space, accommodation area, mess area and helm

Public Address - Raymarine 430 with 2 speakers in wheelhouse roof

Charts - All current charts for operational areas, hard copies and electronic

Navigation Lights - Yes

Air Horn - Yes

Barometer and Clock - One each at main helm station

EPIRB - 2 x 406 + 2 x 406 life rafts

SART - Simrad SA SO

Broad Band Internet - KVH Tracphone

Sat Phone - 1 x Globalstar

Sat Fax - 1 x Globalstar

Inmarsat - Yes

TV-Stereo-DVD-VHS-CD - 9 setc LG

Fog Horn - Distress signaling type

Engine(s)

Main Engines - 2 x Caterpillar C32 – 1007 Kw @ 2,100 rpm – Control station at main helm and main deck starboard side

Auxiliary Engines - 3 x 80 Kw Caterpillar, 440 volt 3 phase

Maximum Speed - 14 knots @ 2,100 rpm

Cruising Speed - 12 knots @ 1,800 rpm

Economic Speed - 8 knots @ 1,200 rpm

Fuel Consumption - 20 litres/hour at anchorage
- 280 litres/hour at economic speed
- 370 litres/hour at cruising speed
- 540 litres/hour at maximum speed

Range - 2,000 nautical miles (with 10% reserve)

Safety Equipment

Full safety and firefighting to meet Class rules

Certification

All newbuild ships and boats are built to IACS Classification and flag state rules pertaining to the country of destination.
