Description

Year constructed: New build
Port of registry: TBA
Classification: LR

Specifications

Accommodation

Suspension seat for helmsman

Bench seats for crew

Storage

Construction

Marine grade aluminium plate

Deadweight: 1.5 Tonnes

Deck Strength: 1.5 tonnes/m2

Clear Deck Area: 15 m2

Fuel Oil Capacity: 300 litres

Equipment

Fendering: Half round rubbing strake with aircraft tyres

Handling: Boat Hooks, Grapple with Lanyard

Deck Equipment: Recessed tie downs SWL 500 kg

Mooring: Double Bit Bollards – 5 sets

Plating: 5.0 mm deck

Access to water – rescue zone – wharf boarding: 1,150 mm from waterline

Anchor: 1 x 20 kg bow c/w 40 m rope

Bilge System: Mechanical pump with electric back-up connected to manifold system. Electric automatic pump in all spaces. Central bilge alarm panel to helm station

Navigation Equipment

Sounder: 1 unit

VHF Radio: 1 unit

Compass: Furuno SC50

AIS: Simrad MX 535 A

Search Light: 1 x Sanshin HR-1012

Navigation Lights: Class approved

Fog Horn: Distress signalling type

Engine(s)

Main Engines: 1 x 130 HP Caterpillar or similar

Cooling System: Keel cooling

Exhausts: Wet

Batteries: 1 bank for main engine, one emergency bank above weather deck. Rotary colhersee switch to all

Tools: Frontline tools, equipment and testing tools for preventative maintenance and on-board breakdowns

Electrics

Navigation Lights: Port, Starboard, Masthead, Stern & Anchor. 1 x towing, 1 x all round white, 2 x all round red

Floodlights: 1 x forward and1 x aft

Search lights: 1 set

Deck lights: 6 units recessed

Safety Equipment

General Emergency Alarm: Yes

Man Over Board Rings: 2 with lights and lanyards

Solas Life Jackets: 8

Parachute Rocket Flares: 4 as per survey requirements

Hand Held Flares: 8 as per survey requirements

First Aid Kits: 1

Torches: 1 x Signalling

Fixed Fire Fighting System: Fitted in machinery spaces CO2
